Features
• Long range visible light camera and thermal imaging camera integrating design, realizing day and night monitoring
• Universal, variable speed pantilt, realizing all-around, no-blind-corner monitoring and high precision location
• Featured laser night vision technology, see target clearly at night in 0 Lux environment
• Laser rangefinder, GPS optional
• Integrated intelligent temperature controlling system, making sure electronic device inside the housing work normally 24/7
• Passive infrared thermal imaging, good concealment, not easy to be perceived
• Professionally designed housing, artistic, light, solid, high temperature resistant, anti-corrosion, water-proof, anti-acid rain
• Low power consumption, little heat generation, stable working performance
Tech Data
| Distance | Visible light Camera | Day vision 8~15km, night vision 4~5km (object: human) |
| Thermal Camera | Target | Human(1.8m×0.5m） | Vehicle (2.3m×2.3m） |
| Detection | 6440m | 18400m |
| Recognition | 1610m | 4600m |
| Identification | 800m | 2300m |
| Visible light camera | Focal length | 16.7~1000mm |
| FOV | 0.45°~25° |
| Auto iris | DC drive |
| Fog penetrating | Supporting |
| Auto focus | Supporting |
| Wiper | Supporting |
| Sensor | 1/1.8''Progressive Scan CMOS |
| Color mode | ICR double filter, day＆night switch |
| Shutter speed | Auto and manual adjustment |
| Camera control | Auto gain control, auto white balance, supporting manual and auto day & night mode switch |
| Fog penetrating | Open /Close is optional |
| WDR | Open/Close is optional |
| Back focus fine adjustment | Supporting, can remotely debug |
| Noise reduction | 3D digital noise reduction |
| Code format | H.264/MJPEG/MPEG4 |
| Video resolution | 1080p, supporting three stream |
| Video code rate | 32Kbps~16Mbps |
| Video frame rate | 50Hz:25fps(1920×1080),25fps (1280×720) 60Hz:30fps(1920×1080),30fps (1280×720) |
| Title overlay | Logo, date, time |
| Image adjustment | Brightness, contrast, saturation, sharpness etc. |
| Thermal camera | Detector Type | Uncooled microbolometer Focal array detector, VOx |
| Pixel | 640×512 |
| Spectrum Range | 8～14μm |
| NETD | ≤50mK@F1.0, 300K |
| Focal lenth | 20～230mm，11.5x optical zoom |
| FOV | 2.7°×2.1°～30.4°×24.5° |
| IFOV | 0.07～0.85mrad |
| Lens control | Electronic zoom/focus, auto focus |
| Image process | DDE, 10 Pseudo Color |
| Laser Illuminator | Focal lenth | 60mmHD focus laser lens |
| Coating | Multilayer near-infrared coating |
| Axis adjusting | Outside MMA |
| Power | 20W |
| Wavelength | 810/808 |
| Lighting angle | 0.5°~27° continuous zoom |
| Laser switch | Auto/manual |
| Laser range finder(Optional) | Max range | 10km (In the mode of mid-latitudes atmosphere,T=20℃, relative humidity 70%,1 standard atmospheric pressure, horizontal visibility>23.5km） |
| Max range | 10000mm |
| Range(3m*3m) | ≥6000m |
| Laser wavelength | 1570nm |
| Min range | 50m |
| Repetition frequency | 1Hz |
| Precision | ±1m |
| Beam Divergence | 0.6~0.8mrad |
| Pantilt | Pan angle | 360°, continuous rotation |
| Tilt angle | -60°~+20° |
| Pan speed | 0.1°~ 12°/s |
| Tilt speed | 0.1°~8°/s |
| Preset | 128 |
| Preset precision | ±0.1° |
| Auto cruise | 2 path, 64 presets each path |
| Auto line scan | 1 path |
| Communication protocol | Pelco-D、Pelco-P optional |
| Bit rate | 2400/4800/9600/19200 bps optional |
| Interface | Power | DC30V |
| Internet | 1×10Base-T/100Base-TX, RJ45 interface |
| Environment | Operation temperature | -25℃~+55℃ |
| Storage temperature | -40℃~+65℃ |
| International protection | IP66 |
| Salt fog proof | PH6.5～7.2, Continuously spraying 48 hours |
| Power | Whole power supply | DC30V±1.0%, accompanied with 220VAC～30VDC wide range power adapter |
| Power consumption | ≤180W |
