Features
• High resolution uncooled microbolometer infrared focal plane arrays, vox
• 17 µm pixel, image quality fine, observe small target more clearly, further detection distance
• High sensitivity, NETD can reach 50mk and frame at 25Hz
• Image noise reduction processing, add DDE function; output hot white/ hot black/pseudo color
• Low power consumption, quick start-up, stable performance, image clearly with high uniformity
• IP output
• Simple operation, easy to use and maintain
• Precision casting aluminium alloy shell, sealed and waterproof, nitrogen inside, anti-harsh environment, overlength working lifetime
Specification
| Type | FS-UHR196 | FS-UHR230 |
| Monitoring distance | Object | People(1.8m×0.5m) | Vehicle(2.3m×2.3m) |
| Detection | 4420m | 11980m |
| Recognition | 1230m | 2970m |
| Identification | 570m | 1440m |
| Thermal lens | Focal length | 30～180mm, 6x optical zoom | 20～230mm, 11.5x optical zoom |
| FOV | 3.5°×2.8°～20.6°×16.5° | 2.7°×2.2°～30.4°×24.6° |
| F | 1.0 ~ 1.2 |
| Lens control | E zoom/focus, auto focus |
| Detector | Detector type | Uncooled FPA detector(vox) |
| Resolution | 640×480 |
| Spectrum | 8～14μm |
| NETD | ≤50mK |
| Frame | 25Hz |
| FFC | Auto/Manual/scene |
| Image process | DDE, pseudo color |
| Pan-tilt | Rotate angle | Pan: 0°~ 360°; Tilt: +20°~ -60° |
| Rotate speed | Pan: 0.1°/s ~ 9°/s; Tilt: 0.1°/s ~ 4°/s |
| Preset | 200 |
| Auto cruise | 8 paths, each has 10 presets |
| Protocol | Pelco-D, Pelco-P optional |
| Protection | IP66 |
| Interface | Power supply interface | DC30V |
| Control interface | 1×10Base-T/100Base-TX, RJ45 |
| Environmental indicators | Working temperature | -25℃～+55℃(-40℃～+55℃ customized) |
| Storage temperature | -40℃～+65℃ |
| International protection | IP66 |
| Anti-vibration | GB/T 4857.10-2005 |
| Anti-impact | GB/T 15412-94 Free drop test method |
| Anti-thunder | 2000V |
| Power supply | Power supply | DC30V(equip with width input power adapter) |
| Power consumption | ≤80W |
| Physical features | Weight | ≤17Kg |
| Size(L×W×H, contain sunshield cover) | 440mm×213mm×532mm |
| Installation | Outdoor base installation |
