Features
• Adopting continuous zooming thermal imaging technology, imaging clearly, can search in large area and recognize objectives in long distance
• Infrared detector with high temp sensitivity, with min temp resolution of 50mK
• Day and night 2 megapixels low illuminating color camera, realizing day and night continuous monitoring
• Optional auto focusing function, realizing multiple focusing mode and triggering mode
• Optional thermal imaging camera presetting function, remembering FOV of each preset bit, enhancing working efficiency
• Professionally designed shell, artistic, light, firm, anti-high temp, anti-corrosion, water proof, anti-acid rain
Technical Data
| Monitor distance | Visible light | Day vision | 1100m for human action recognition |
| Thermal Camera | Object | Human(1.8m×0.5m) | Vehicle(2.3m×2.3m) |
| Detection | 4200m | 12000m |
| Recognition | 1050m | 3000m |
| Identification | 520m | 1500m |
| Thermal lens | Focal length | 30-150mm, 5× optical zoom |
| FOV | 4.2°×3.1°-14.6°×11.0° |
| F value | F1.0 |
| Thermal Detector | Detector type | uncooled microbolometer focal plane array（VOX） |
| Resolution | 640×512 |
| Spectral range | 8～14μm |
| NETD | ≤50mK@F1.0,300K |
| Image processing | DDE, pseudo color |
| HD Camera | Focal length | 4.5～135mm, 30× optical zoom |
| Auto focusing | supporting |
| Sensor type | 1/2.8” Progressive Scan CMOS |
| Code | H.264/MJPEG/MPEG4 |
| Video resolution | 1080P, CIF, supporting three stream |
| Video frame rate | 1～25f/s(50Hz), 1～30f/s(60Hz) |
| Pan-tilt | Carrying capacity | 22kg (top load) |
| Angle | Horizontal 360°continuous rotation,pitching: -45°～+45° |
| speed | Horizontal 0.01°～9°/s, pitching 0.01°～4°/s |
| Preset | 255 |
| Cruising | 2 paths, 64 bits each path |
| Anti-lightning | 2000V |
| Interface | Power supply | DC30V |
| Network interface | 1×10Base-T/100Base-TX, RJ45 |
| Environment indicators | Working temp | -25℃～+55℃ |
| Storage temp | -40℃～+65℃ |
| Protection grade | IP66 |
| Power | Power supply | Wide range input, AC90～305V to DC30V waterproof power |
| Power consumption | ≤90W |
