Product Features
• Synchronous zooming laser illuminating system, long illuminating distance, large illuminating range, realizing monitoring in 0Lux complete black
• Day and night low illuminance 2 megapixels color to black camera, day and night continuous monitoring
• MCIC multi-tube core fusion mixed mode light homogenization technology, no speckle and dark ring, high edge definition
• Supporting fog penetration, backlight compensation, multistage wide dynamic
• Optional auto focusing function, realizing multiple focusing mode and triggering mode
• Supporting camera back focal length fine adjustment technology and camera remote debugging
• Supporting long focal length speed limit and 3D locating function
• Abundant network protocol and good network applicability, adapting all kinds of network environment
• External MMA fine adjustment mechanism, no need to disassemble to complete laser alignment adjustment
• Professionally designed shell, artistic, light, firm, anti-high temp, anti-corrosion, water proof, anti-acid rain
Specification
| Monitoring distance | Night vision | 3100 meters |
| Day vision | 5100m-8100 meters |
| Imaging lens | Focal length | 20~750mm |
| FOV | 0.5°~17.8° |
| Auto focusing | Supporting(optional) |
| Fog penetration | Supporting(optional) |
| Camera | Sensor type | 1/1.8” Progressive Scan CMOS |
| Coding mode | H.264/MPEG4/MJPEG |
| Video resolution | 1080P, CIF, supporting three streams |
| Video bit rate | 32Kbps~16Mbps |
| Video frame rate | 1~25F/S(50Hz),1~30F/S(60Hz) |
| Illuminator | Illuminating lens | 60* zooming laser telephoto lens |
| Power | 15W |
| Wave length | 810nm |
| Illuminating angle | 0.3°~30°continuous changing |
| Light homogenization | multi-tube core fusion mixed mode light homogenization technology |
| Shield | Material | Precise casting aluminum alloy |
| Window glass | 4mm crystallite super white optical glass |
| Pan-tilt | Carrying capacity | 50kg (top load) |
| Angle | Horizontal 360°continuous rotation, pitching -45°~+45° (-60°~+20° optional) |
| Speed | Horizontal 0.01°~12°/pitching 0.01°~8°/s |
| Preset bits | 255 bits, supporting lens zooming, focusing and preset bits |
| Auto cruising | 8 paths,10 preset bits each path |
| Anti-lightning | 2000V |
| Interface | Power supply interface | AC24V |
| Network interface | 1×10Base-T/100Base-TX, RJ45 |
| Environment indicators | Working temp | -25℃~+55℃ |
| Storage temp | -40℃~+65℃ |
| Protection grade | IP66 |
| Power supply | Whole machine power supply | AC24V±10%, appendant AC220V~AC24V/5A water proof power supply |
| Whole machine power consumption | ≤150W |
| Physical features | Weight | 50kg |
| Installation method | outdoor pedestal mounting |
